ATHENA OIL SEAL 17x28x5, M730000776000, YAMAHA 93102-17342

ATHENA OIL SEALS - M730000776000

Description

Oil seal has generally the function of retaining a fluid, preventing its leaking. The outside has to ensure a fixed-fitting in the seat and its tightness. Thanks to its specific profile together with the radial force applied by the spring and the characteristics of the elastomer, the sealing lip flows on the shaft creating a barrier that prevents the leakage of the fluid both in static and dynamic condition. Every Athena oil seal is in accordance with the DIN 3760 requirements. Oil seals are available in different sizes, shapes and dimensions.

Technical features

• External Diameter (mm) 28.00
• Height 5.00
• Internal Diameter (mm) 17.00
• Net Weight (Kg) 0.01
• Number Of Components 20
• Type SC

Partner OEM code

• APRILIA 8206214
• BENELLI R11240051A0
• BETA 3301460000
• ITALJET 9511006
• MALAGUTI 75311700
• M B K 9310217342
• MOTORI MINARELLI 5305409
• YAMAHA 9310217841
• YAMAHA 9310217811
• YAMAHA 9310217342

Vehicle Compatibility

• 2001 VINO - YJ50RN CLUTCH
• 2002 VINO CLASSIC - YJ50RAP CLUTCH
• 2002 YJ50RP CLUTCH
• 2003 VINO - YJ50RR CLUTCH
• 2003 VINO CLASSIC - YJ50RAR CLUTCH

Part No. 58-8163.ATH

�

�

�

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
