WOSSNER 66mm PISTON KIT YAMAHA RS350 1973-1975

Piston kit 66mm Bore 65.93 Wossner 8221D200 (+2.00mm)

YAMAHA
350 R5 1973 - 1975,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W9898.200.WO
YAMAHA 350 R5 1973-1975,
WOSSNER PISTON KIT 8221D200 O/S +2.00 BORE 66.00mm
Clips. CW16,
Pin. WP027,
Rings. RSB6600 x 2

Display (cm3) 347
Hub stroke (mm) 54.00
Clearance (mm) 0.07
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3) -
Compression height (mm) 36.00
Theorectical weight (G)

�

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
