WOSSNER 88mm PISTON KIT A, KTM 350 EXC-F 12-16, FREERIDE 12-17, HUSQ FE350 14-16

Piston kit 88mm BORE 87.95 Wossner 8885DA (STD)

HUSABERG
FE350 2014 -,

KTM
EXC-F 350 2013,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W960.A.WO (oro2u)
KTM 350 EXC-F (2012-2015), KTM 350 XC-F (2012-2015), KTM 350 XCF-W (2012-2015), KTM Freeride 350 (2012-2014), Husaberg FE350 (2013-2014), Husqvarna FE350 (2014),

Wossner Piston KTM EXC-F 87.95mm Bore
Lock P/N CW18
Pin P/N WP054
Ring Set P/N 880XSY
Rod P/N P4061

Display (cm3) 349
Hub stroke (mm) 57.50
Clearance (mm) 0.05
Wossner compression Ratio: OEM
OEM Compression ratio: 12.30:1
Dome volume (cm3) -0.10
Compression height (mm) 20.50
Theorectical weight (G)

Cross reference numbers ONLY.
77230107100-I, 40056M08800, 77530107100

�

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
