WOSSNER 67mm PISTON KIT SUZUKI TS200R ALL

Piston kit 67mm BORE 66.93 Wossner 8046D100 (+1mm)

SUZUKI
TS200R

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W957+100.WO (oro2u.com)SUZUKI TS200R ALL YEARS,PISTON KIT 8046D100
RINGS RSB6700 x 2
C-CLIPS CW18
PIN WP033

Display (cm3) 200
Hub stroke (mm) 56.80
Clearance (mm) 0.07
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3) -
Compression height (mm) 28.50
Theorectical weight (G)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
