PISTON KIT 02-04 KX250 66.40 B WOSSNER 8088DB KAWASAKI MX

Piston Kit � 66.41mm Bore 66.35 Wossner 8088DB (+0.01MM)

KAWASAKI
KX250 2002 - 2004,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W799.B.WO (oro2u.com)
Wossner Piston Kawasaki KX250 66.41 mm Bore (PN# 8088DB)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RDB6640
Rod P/N P2022

Display (cm3) 249
Hub stroke (mm) 72.00
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 37.00
Theorectical weight (G)

�
