WOSSNER 69mm PISTON KIT B, KAWASAKI KDX220R 1997-2005

Piston kit 69.01mm Bore 68.95 Wossner 8092DB (+0.01)

KAWASAKI
KDX220R 1998 - 2005,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W750.B.WO
Wossner Piston Kawasaki KDX220 69.01 mm Bore (PN# 8092DB)
Lock P/N CW16
Pin P/N WP027
Ring Set P/N RSB6900 X 2
Rod P/N P2033

Display (cm3) 216
Hub stroke (mm) 58.00
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 32.00
Theorectical weight (G)

Select your car to see if this product fits:
- 1998 Kawasaki KDX 220 - 1999 Kawasaki KDX 220 - 2000 Kawasaki KDX 220 - 2001 Kawasaki KDX 220

- 2002 Kawasaki KDX 220 - 2003 Kawasaki KDX 220 - 2004 Kawasaki KDX 220 - 2005 Kawasaki KDX 220

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
