WOSSNER 50.5mm PISTON KIT SUZUKI LT80 1987-2006, KAWASAKI KFX80 2003-2006

The 50.50mm Bore Wossner Piston Kit (Part No. 8282D050) is a +0.50 oversized forged piston suitable for Kawasaki KFX80 (2003–2006) and Suzuki LT80 (1982) models. Manufactured in Germany, it is designed with an elliptical profile for consistent pressure distribution and optimal performance under thermal expansion. This design also aids in effective combustion heat transfer to the cylinder walls, supporting engine reliability in two-stroke applications.

Features

• Forged piston for enhanced strength and longevity

• Facilitates effective heat dissipation from the combustion chamber

• Elliptical shape promotes even pressure and load distribution

• Reduces risk of piston collapse due to thermal stress

• Made in Germany

Specifications

• Bore Size: 50.50 mm

• Actual Bore: 50.44 mm

• Clearance: 0.06 mm

• Compression Height: 27.00 mm

• Stroke: 42.00 mm

• Displacement: 82 cm³

• Compression Ratio: 2-stroke (Wossner and OEM)

Vehicle Fitments

• 2003 Kawasaki KFX80

• 2004 Kawasaki KFX80

• 2005 Kawasaki KFX80

• 2006 Kawasaki KFX80

• 1982 Suzuki LT80

Included Components

• Lock: CW12

• Pin: WP059

• Ring Set: RSB5050

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
