PISTON KIT 88-00 KX80 47.00 B WOSSNER 8234DB KAWASAKI MX

Wossner forged piston kit with a 47.01mm bore (46.96mm actual) is specifically engineered for Kawasaki KX80 models from 1988 to 2000, including variants with international bore specifications. Precision-forged in Germany, the piston’s elliptical design improves thermal expansion behaviour, allowing even stress distribution and reducing the risk of piston failure due to localised pressure or collapse.

Features

• High-strength forged piston for performance and durability

• Elliptical shape distributes thrust loads uniformly under heat expansion

• Optimised heat transfer from combustion chamber to cylinder wall

• Manufactured in Germany with precise tolerances for international bore specs

Specifications

• Bore Size: 47.01mm (Actual: 46.96mm)

• Compression Height: 26.00mm

• Clearance: 0.05mm

• Stroke: 45.80mm

• Displacement: 79 cm³

• Wossner Compression Ratio: 2-stroke

• OEM Compression Ratio: 2-stroke

Cross-Reference OEM Part Numbers

• Piston Kit: 8234DB

• Lock: CW14

• Pin: WP058

• Ring Set: RSB4700

• Rod: P2005

Vehicle Fitments

• Kawasaki KX80 (1988–2000)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
