PISTON KIT 88-00 KX80 47.00 A WOSSNER 8234DA KAWASAKI MX

Wossner forged piston kit with a 47.00mm bore (46.95mm actual) is designed for Kawasaki KX80 models from 1988 to 2000. Manufactured in Germany, this piston features an elliptical design that ensures balanced load distribution and thermal expansion management. Engineered for performance, it promotes efficient heat transfer from the combustion chamber to the cylinder wall, helping to reduce stress points and prevent piston collapse.

Features

• Forged piston design for maximum strength

• Efficient heat transfer enhances engine reliability

• Elliptical shape distributes mechanical load evenly

• Reduces localised stress and risk of collapse under expansion

• Precision manufactured in Germany

Specifications

• Bore Size: 47.00mm (Actual: 46.95mm)

• Compression Height: 26.00mm

• Clearance: 0.05mm

• Stroke: 45.80mm

• Displacement: 79 cm³

• Wossner Compression Ratio: 2-stroke

• OEM Compression Ratio: 2-stroke

Cross-Reference OEM Part Numbers

• Piston Kit: 8234DA

• Lock: CW14

• Pin: WP058

• Ring Set: RSB4700

• Rod: P2005

• Cross Reference: 669M04700

Vehicle Fitments

• Kawasaki KX80 (1988–2000)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
