WOSSNER 69mm PISTON KIT SUZUKI RM250 1989-1995, RMX250 1989-1999

The Wossner 8022D100 piston with a 69mm bore (68.94mm actual size) is engineered for high durability and strength, fitting Suzuki RM250 (1989-1995) and RMX250 (1993-1995) models. Forged in Germany, it is designed to maximise heat transfer from the combustion chamber to the cylinder walls. The elliptical piston shape promotes even distribution of thrust loads under heat expansion, reducing localised stresses and preventing piston collapse.

Features

• Forged construction for enhanced strength and resilience

• Optimised for efficient heat transfer to cylinder walls

• Elliptical design for uniform load distribution under thermal expansion

• Manufactured in Germany

Specifications

• Bore: 69mm (actual size 68.94mm)

• Part Number: 56-W642_200.WO

• Lock Part Number: CW18

• Pin Part Number: WP033

• Ring Set Part Number: RSB6700 x 2

• Displacement: 246 cm³

• Stroke: 70.80mm

• Clearance: 0.06mm

• Wossner Compression Ratio: 2-stroke

• OEM Compression Ratio: 2-stroke

• Compression Height: 37.00mm

Cross-Reference OEM Part Numbers

• Piston: 12110-28C11-0F0, 12110-29E20-0F0

• Ring, Piston: 12141-41600, 12141-41620

• Pin, Piston: 12151-28C00, 12151-37F00

• Circlip: 09381-18002

Vehicle Fitments

• 1989-1995 Suzuki RM250

• 1993-1995 Suzuki RMX250

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
