WOSSNER 55mm PISTON KIT KAWASAKI KX125 1993

Wossner Forged Piston Kit 55.00mm Bore – Kawasaki KX125 (1992–1993)
This Wossner forged piston kit is engineered for Kawasaki KX125 models from 1992 to 1993. With a bore size of 55.00 mm and a piston diameter of 54.94 mm (+1.00 mm oversize), it is ideal for extensively overbored or reconditioned cylinders. The forged construction enhances durability and thermal resistance, while the elliptical design ensures even thrust load distribution to minimise wear and prevent piston failure. Manufactured in Germany for high precision and performance.

Features

• Forged piston construction for superior strength and heat resistance

• Elliptical design reduces localised pressure and distributes loads evenly

• Optimised for efficient combustion chamber heat transfer

• Precision-manufactured in Germany for consistent quality

Specifications

• Bore Size: 55.00 mm

• Piston Diameter: 54.94 mm

• Engine Displacement: 125 cm³

• Stroke: 54.50 mm

• Clearance: 0.06 mm

• Compression Height: 29.00 mm

• Compression Ratio: 2-stroke (Wossner and OEM)

Cross-Reference Wossner Part Numbers

• Piston Kit: 8110D100

• Lock: CW16

• Pin: WP036

• Ring Set: RSB5500

• Rod: P2037

Vehicle Fitments

• 1992 Kawasaki KX125

• 1993 Kawasaki KX125
