WOSSNER 67.5mm PISTON KIT SUZUKI LT250R 1987

Wossner Forged Piston Kit 67.50mm Bore – Suzuki LT250 1987 (8258D050 +0.50)
This Wossner forged piston kit is tailored for the 1987 Suzuki LT250 ATV, featuring a +0.50mm oversize bore (actual 67.44mm). Designed for enhanced performance in 2-stroke engines, it features forged construction for superior strength and thermal management. The elliptical shape of the piston ensures even thrust load distribution, reducing stress and risk of failure during high thermal expansion. Precision manufactured in Germany.

Features

• Forged piston design for increased strength and longevity

• Engineered for efficient heat dissipation from the combustion chamber

• Elliptical profile ensures uniform bearing surface under heat expansion

• Developed for 2-stroke engine use

• Made in Germany

Specifications

• Bore Size: 67.50mm (+0.50 oversize)

• Actual Bore: 67.44mm

• Compression Height: 37.20mm

• Clearance: 0.06mm

• Stroke: 70.00mm

• Displacement: 246 cm³

• Wossner Compression Ratio: 2-stroke

• OEM Compression Ratio: 2-stroke

Cross-Reference OEM Part Numbers

• Wossner Piston: 8258D050

• Ring Set: RSB6750 (x2)

• Lock: CW18

• Pin: WP033

• Internal Reference: 56-W577+0.50.WO

Vehicle Fitments

• 1987 Suzuki LT250

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
