WOSSNER 71.5mm FORGED PISTON KIT SUZUKI LT250R 1985-1986

Wossner Forged Piston Kit 71.50mm Bore – Suzuki LT250RF/RG (8257D150 +1.50)
This Wossner forged piston kit is engineered for Suzuki LT250RF and LT250RG ATV models from 1985–1986. With a bore size of 71.50mm (+1.50 oversize), this high-performance component offers superior durability and efficient heat transfer. Designed with an elliptical profile, the piston ensures even distribution of thrust loads and minimizes the risk of piston collapse under high thermal stress. Manufactured in Germany to high precision standards.

Features

• Forged piston construction for enhanced strength and durability

• Engineered for optimal combustion chamber heat transfer

• Elliptical design improves load distribution and reduces pressure points

• Designed for 2-stroke engines

• Made in Germany

Specifications

• Bore Size: 71.50mm (+1.50 oversize)

• Actual Bore: 71.44mm

• Compression Height: 33.00mm

• Clearance: 0.06mm

• Stroke: 64.80mm

• Displacement: 249 cm³

• Wossner Compression Ratio: 2-stroke

• OEM Compression Ratio: 2-stroke

Cross-Reference OEM Part Numbers

• Wossner Piston: 8257D150

• Ring Set: RSB7150 (x2)

• Lock: CW18

• Pin: WP033

• Rod: P2045

• Internal Reference: 56-W576+1.50.WO

Vehicle Fitments

• 1985 Suzuki LT250RF

• 1985 Suzuki LT250RG

• 1986 Suzuki LT250RF

• 1986 Suzuki LT250RG
