WOSSNER 68.5mm PISTON KIT SUZUKI LT250R 1988-1992

The Wossner 8259D150 piston kit is specifically engineered for Suzuki LT250 ATV models from 1988 to 1992, featuring a 68.50 mm bore for +1.50 mm oversize applications. Forged in Germany to the highest standards, this piston provides superior strength and optimal heat management. The elliptical design allows for uniform load distribution during thermal expansion, effectively reducing localised pressure and the risk of piston collapse. This comprehensive kit includes all essential components for a reliable engine rebuild.

Features

• High-strength forged piston construction

• Designed for efficient heat transfer from the combustion chamber

• Elliptical profile promotes uniform bearing surface under thermal expansion

• Reduces localised stress to help prevent piston failure

• German-engineered for consistent performance and durability

Specifications

• Bore Size: 68.50 mm

• Actual Bore Diameter: 68.44 mm

• Stroke: 70.00 mm

• Display Displacement: 246 cm³

• Clearance: 0.06 mm

• Compression Ratio (Wossner and OEM): 2-stroke

• Compression Height: 37.20 mm

Cross-Reference Wossner Part Numbers

• Piston Kit: 8259D150

• Lock: CW18

• Pin: WP033

• Ring Set: RSB6850 (Quantity: 2)

• Part No.: 56-W571+1.50.WO

Vehicle Fitments

• Suzuki LT250 (1988–1992)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
