WOSSNER 67.5mm PISTON KIT SUZUKI LT250R 1988-1992

The Wossner 8259D050 piston kit is engineered for Suzuki LT250 ATV models from 1988 to 1992, featuring a 67.50 mm bore for +0.50 mm oversize applications. Manufactured in Germany from forged materials, this piston provides superior durability and optimised heat transfer. Its elliptical shape promotes even bearing surface contact under heat expansion, reducing localised stress and preventing piston collapse. The kit includes all necessary components for a reliable engine rebuild.

Features

• Forged piston construction for maximum strength and durability

• Engineered for optimal heat dissipation from combustion chamber to cylinder wall

• Elliptical profile ensures even distribution of thermal expansion pressure

• Reduces localised stress to prevent piston collapse

• Precision-manufactured in Germany

Specifications

• Bore Size: 67.50 mm

• Actual Bore Diameter: 67.44 mm

• Stroke: 70.00 mm

• Display Displacement: 246 cm³

• Clearance: 0.06 mm

• Compression Ratio (Wossner and OEM): 2-stroke

• Compression Height: 37.20 mm

Cross-Reference Wossner Part Numbers

• Piston Kit: 8259D050

• Lock: CW18

• Pin: WP033

• Ring Set: RSB6750 (Quantity: 2)

• Part No.: 56-W571+0.50.WO

Vehicle Fitments

• Suzuki LT250 (1988–1992)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
