WOSSNER 89mm PISTON KIT SUZUKI LT500R 1987-1990, Pro-Lite

Wossner forged piston kit for the Suzuki LT500R ATV (model years 1987–1990), featuring a +3.00 mm oversize bore at 89.00 mm. This piston is engineered to deliver high performance and reliability in 2-stroke engine applications. It features a forged construction and an elliptical profile for consistent thermal expansion and balanced load distribution, minimising wear and reducing the risk of piston collapse. Manufactured in Germany to strict quality standards.

Features

• Forged piston design for superior strength and durability

• Engineered for effective combustion chamber heat dissipation

• Elliptical shape ensures uniform load distribution and reduced stress under heat

• Designed specifically for 2-stroke engine performance

• Precision-manufactured in Germany

Specifications

• Bore: 89.00 mm

• Actual Bore Diameter: 88.91 mm

• Compression Height: 45.00 mm

• Display Volume: 498 cm³

• Stroke: 86.00 mm

• Clearance: 0.09 mm

• Compression Ratio: 2-stroke (Wossner and OEM)

Cross-Reference OEM Part Numbers

• Piston Kit Part No.: 8260D300

• Lock P/N: CW18

• Ring Set P/N: RSC8900 (x2)

• Alternate Part No.: 56-W561+3.00.WO

Vehicle Fitments

• Suzuki LT500R (1987–1990)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
