PISTON KIT 83-87 YZ250 68.00 WOSSNER 8133DA YAMAHA MX
PISTON KIT 83-87 YZ250 68.00 WOSSNER 8133DA YAMAHA MX
Couldn't load pickup availability
This Wossner 68.00mm standard size forged piston kit is designed for Yamaha YZ250 models from 1983 to 1987. Manufactured in Germany, it features a high-strength forged construction and an elliptical piston design to ensure uniform load distribution during heat expansion, reduce localised stress, and promote consistent engine performance. The piston supports efficient thermal transfer from the combustion chamber to the cylinder walls, making it suitable for demanding two-stroke applications.
Features
-
Forged piston for high durability and structural strength
-
Elliptical design maintains a uniform bearing surface under thermal expansion
-
Distributes thrust loads evenly to minimise stress and prevent piston collapse
-
Optimised for efficient heat transfer from combustion chamber to cylinder walls
-
Manufactured in Germany
Specifications
-
Bore: 68.00mm
-
Actual diameter: 67.94mm
-
Displacement: 246 cm³
-
Stroke: 68.00mm
-
Clearance: 0.06mm
-
Compression height: 36.00mm
-
Compression ratio: 2-stroke
Cross-Reference OEM Part Numbers
-
Piston Kit Part No.: 56-W560+000.WO
-
Wossner Piston Kit No.: 8133DA
-
Lock: CW18
-
Pin: WP033
-
Ring Set: RSB6800 x2
-
Rod: P2048 (for 1983–1989 models)
-
Cross-reference numbers: 39X-11630-00-00, 560M06800
Vehicle Fitments
-
Yamaha YZ250 1983
-
Yamaha YZ250 1984
-
Yamaha YZ250 1985
-
Yamaha YZ250 1986
-
Yamaha YZ250 1987
Majority of our listings are for a direct replacement for your original part.
Our parts are made of quality and are designed to meet or exceed the original OEM Standards.
Our products are often a cost effective alternative to genuine OEM Parts.
Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
