WOSSNER 47.5mm PISTON KIT SUZUKI RM80 1986-1987

This Wossner forged piston kit features a 47.50mm bore (47.45mm actual) and is designed for the Suzuki RM80 models from 1986 to 1987. Engineered for durability and thermal performance, the piston facilitates effective combustion heat transfer and uses an elliptical design to ensure even pressure distribution. This reduces the risk of localised stress and piston collapse. Manufactured in Germany, this standard size piston kit includes matching components for compatibility with 2-stroke engine specifications.

Features

• Forged piston construction for enhanced durability

• Efficient heat transfer design to support engine performance

• Elliptical profile for even bearing surface under expansion

• Manufactured in Germany

• Standard bore piston for Suzuki RM80 (1986–1987)

Specifications

• Bore Size: 47.50mm (actual 47.45mm)

• Compression Height: 27.00mm

• Clearance: 0.05mm

• Stroke: 46.80mm

• Display Displacement: 80 cm³

• Compression Ratio: 2-stroke (Wossner and OEM)

Vehicle Fitments

• Suzuki RM80 1986

• Suzuki RM80 1987

Included Components

• Piston: Wossner 8227DA

• Lock: CW14

• Pin: WP058

• Ring Set: RSB4750

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
