WOSSNER 96mm HC FORGED PISTON KIT HONDA CRF450R 2009-2012

Piston kit 96.02mm Bore 95.98 Wossner 8768DB (+0.02)

HONDA
CRF450R 2009 - 2012,
(High compression 2 - rings)

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

Part No. 56-W4978.C.WO.H
Wossner Piston Honda CRF450R 96 mm Bore (PN# 8768DC)
Lock P/N CW19
Pin P/N WP037
Ring Set P/N 960ADS-2
Rod P/N P4027

Display (cm3) 449
Hub stroke (mm) 62.10
Clearance (mm) 0.04
Wossner compression Ratio:13.40:1
OEM Compression ratio: 12.00:1
Dome volume (cm3) -0.030
Compression height (mm) 20.70
Theorectical weight (G)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
