PISTON KIT 09-12 CRF450R 96 HC WOSSNER 8768DA HONDA FORGED

Wossner high-compression forged pistons are designed for strength and efficient heat transfer, with an elliptical structure that provides uniform bearing surfaces under expansion. This model, with a 96.00mm bore (95.96mm actual size), is specifically built for Honda CRF450R models from 2009 to 2012 and features a two-ring configuration.

Features

• Forged construction for durability
• Elliptical design for even thermal expansion
• High-compression configuration with two-ring design
• Made in Germany

Specifications

• Bore Size: 96.00mm (actual 95.96mm)
• Displacement: 449 cm³
• Stroke: 62.10mm
• Clearance: 0.04mm
• Wossner Compression Ratio: 13.40:1
• OEM Compression Ratio: 12.00:1
• Dome Volume: -0.030 cm³
• Compression Height: 20.70mm

Cross-Reference OEM Part Numbers

• 13110-MEN-A30
• 4979M09600

Vehicle Fitments

• Honda CRF450R 2009–2012

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
