PISTON KIT 08-13 TM85 47.85mm WOSSNER 8285DC TM FORGED

This Wossner forged piston kit, part number 8285DC, features a 47.92mm bore (+0.02mm oversize) and is designed for TM 85 models from 2008 to 2013. Manufactured in Germany, it is built for two-stroke engines, offering superior strength, efficient heat dissipation, and even load distribution through its elliptical design, which helps prevent piston collapse during expansion.

Features

• Forged construction for strength and durability in two-stroke engines
• Elliptical design for balanced expansion and load distribution
• Engineered for efficient combustion chamber heat transfer
• Made in Germany
• Direct OEM replacement
• Easy to install; professional installation recommended if unsure

Specifications

• Bore Size: 47.92mm (+0.02mm)
• Displacement: 85cm³
• Stroke: 47.00mm
• Clearance: 0.05mm
• Compression Ratio: 2-stroke
• Dome Volume: Not specified
• Compression Height: 24.00mm

Cross-Reference OEM Part Numbers

• CW13 (Lock)
• WP124 (Pin)
• RSB4800 (Ring Set)
• P2068 (Rod)

Vehicle Fitments

• TM 85 (2008–2013)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
