WOSSNER 96mm PISTON KIT HC, SUZUKI RM-Z450 2013-2017

This Wossner forged piston kit, part number 8887DC, features a 96.02mm bore with an actual bore size of 95.98mm (+0.02mm oversize). It is specifically designed for high-compression applications in Suzuki RM-Z450 models from 2013 to 2017. Manufactured in Germany, the piston is built for high-performance use, offering increased compression over OEM specifications, and features an elliptical design to ensure even load distribution and superior heat transfer.

Features

• Forged piston for enhanced strength and durability
• High compression design for improved performance
• Elliptical profile for balanced expansion and reduced localized stress
• Engineered for optimal heat transfer from combustion to cylinder walls
• Made in Germany
• Direct OEM replacement
• Easy to install; professional installation recommended if unsure

Specifications

• Bore Size: 96.02mm
• Actual Bore: 95.98mm
• Displacement: 449cm³
• Stroke: 62.10mm
• Clearance: 0.04mm
• Dome Volume: -0.40cm³
• Wossner Compression Ratio: 13.50:1
• OEM Compression Ratio: 12.50:1
• Compression Height: 22.90mm

Cross-Reference OEM Part Numbers

• CW19 (Lock)
• WP071 (Pin)
• 960ADS-2 (Ring Set)
• P4013 (Rod)
• MB83C072C (Main Bearing Right)
• MB830053-4 (Main Bearing Left)

Vehicle Fitments

• RM-Z450 (2013–2017)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
