PISTON KIT 13-14 RMZ450 96 HC WOSSNER 8887DA SUZUKI

This Wossner forged piston kit, part number 8887DA, features a standard 95.96mm bore and is specifically designed for high-compression performance in Suzuki RM-Z450 models from 2013 to 2017. Manufactured in Germany, it offers a significant compression increase over OEM specifications. Its elliptical design enhances durability and distributes loads evenly, making it suitable for demanding applications.

Features

• Forged piston construction for superior strength and durability
• High compression design for increased performance
• Elliptical profile for even expansion and reduced localized stress
• Engineered for optimal heat transfer to cylinder walls
• Made in Germany
• Direct OEM replacement
• Easy to install; professional installation recommended if unsure

Specifications

• Bore Size: 95.96mm (Standard)
• Displacement: 449cm³
• Stroke: 62.10mm
• Clearance: 0.04mm
• Dome Volume: -0.40cm³
• Wossner Compression Ratio: 13.50:1
• OEM Compression Ratio: 12.50:1
• Compression Height: 22.90mm

Cross-Reference OEM Part Numbers

• 12111-15A00
• CW19 (Lock)
• WP071 (Pin)
• 960ADS-2 (Ring Set)
• P4013 (Rod)
• MB83C072C (Main Bearing Right)
• MB830053-4 (Main Bearing Left)

Vehicle Fitments

• RM-Z450 (2013–2017)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
