WOSSNER 56.5mm FORGED PISTON KIT KAWASAKI KX125 1982-1985

The Wossner 8210D050 forged piston kit features a 56.50mm bore size and is designed for Kawasaki KX125 models from 1982 to 1985. Precision-engineered for efficient combustion chamber heat transfer and even thrust load distribution, this German-made piston is elliptically shaped to reduce localized pressure and prevent piston collapse.

Features

• Forged piston for increased strength and durability
• Designed to improve heat transfer from combustion chamber to cylinder walls
• Elliptical design ensures uniform bearing surface under heat expansion
• Prevents localized pressure and piston collapse
• Manufactured in Germany

Specifications

• Bore: 56.50 mm
• Display: 125 cm³
• Hub Stroke: 50.60 mm
• Clearance: 0.06 mm
• Compression Height: 29.70 mm
• Compression Ratio: 2-stroke (Wossner and OEM)
• Dome Volume: Not specified
• Theoretical Weight: Not specified

Cross-Reference OEM Part Numbers

• Piston: 8210D050
• Lock: CW16
• Pin: WP036
• Ring Set: RSB5650 x 2
• Rod: P2037
• Part No.: 56-W486.050.WO

Vehicle Fitments

• Kawasaki KX125 1982–1985

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
