PISTON KIT 03-04 YZF450 95.00 FORGED WOSSNER 8562DB

Wossner forged piston kit designed for superior strength and heat transfer efficiency. Engineered with an elliptical shape to ensure uniform bearing surfaces under heat expansion, reducing localized pressure and preventing piston collapse. Manufactured in Germany for high-performance applications.

Features

• Forged construction for enhanced durability and strength
• Optimized heat transfer for improved combustion efficiency
• Elliptical design for even thrust load distribution
• Made in Germany

Specifications

• Bore Size: 94.97mm (+0.01mm oversize = 95.01mm)
• Displacement: 449 cm³
• Stroke: 63.40mm
• Clearance: 0.04mm
• Compression Ratio: OEM (12.50:1)
• Dome Volume: -9.90 cm³
• Compression Height: 23.50mm
• Theoretical Weight: Not specified

Included Components

• Piston Kit (8562DB)
• Piston Clip: CW18
• Piston Pin: WP053
• Piston Ring: 950ADS-2

Vehicle Fitments

• Yamaha YZ450F (2003-2004)
• Yamaha WR450F (2003-2004)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
