PISTON KIT 73-74 CR250 71.00 FORGED WOSSNER 8152D100

Wossner forged piston kit with a 71.00mm bore, designed for Honda CR250R, MR250, and MT250 models from 1973 to 1974. Engineered for strength and durability, this piston enhances combustion chamber heat transfer and features an elliptical design to ensure even load distribution, reducing localized pressure and preventing collapse. Manufactured in Germany for high performance and reliability.

Features

• Oversized forged piston (+1.00mm) for increased durability
• Elliptical design for even thrust load distribution
• Optimized heat transfer to cylinder walls
• Manufactured in Germany for superior quality

Specifications

• Bore Size: 71.00mm
• Standard Bore: 70.94mm
• Displacement: 248 cm³
• Stroke: 64.40mm
• Clearance: 0.06mm
• Compression Ratio: 2-Stroke
• Compression Height: 32.00mm

Cross-Reference OEM Part Numbers

• Piston Part Number: 8152D100
• Lock Part Number: CW18
• Pin Part Number: WP033
• Ring Set Part Number: RSB7100 X 2

Vehicle Fitments

• Honda CR250R 1973-1974
• Honda MR250 1973-1974
• Honda MT250 1973-1974

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
