WOSSNER 56mm FORGED PISTON KIT KAWASAKI KD125 74-84, KE125 74-84, KS125 74-84

Wossner forged piston kit with a 56mm bore (55.94mm) for Kawasaki KD125, KE125, and KS125 models from 1974 to 1984. Designed for superior strength and heat transfer efficiency, this piston ensures optimal combustion performance. The elliptical design distributes thrust loads evenly, reducing localized pressure and preventing piston collapse. Manufactured in Germany.

Features

• Forged piston for increased strength and durability
• Optimized heat transfer for improved performance
• Elliptical design ensures uniform bearing surface under heat expansion
• Even thrust load distribution to prevent piston collapse
• Manufactured in Germany

Specifications

• Bore Size: 56mm (55.94mm)
• Part Number: 8032DA
• Lock Part Number: CW14
• Pin Part Number: WP025
• Ring Set Part Number: RSB5600 x2
• Displacement: 125 cm³
• Stroke: 50.60mm
• Clearance: 0.06mm
• Compression Ratio: 2-stroke
• Compression Height: 32.00mm

Vehicle Fitments

• Kawasaki KD125 (1974-1984)
• Kawasaki KE125 (1974-1984)
• Kawasaki KS125 (1974-1984)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
