PISTON KIT 002-09 DRZ250 73 HC FORGED WOSSNER 8678D700

Wossner forged high-compression big bore piston kit with an 80mm bore (79.95mm) for Suzuki DR-Z250 (2001-2007). Designed for superior strength and heat transfer efficiency, this piston ensures optimal combustion performance. The elliptical design distributes thrust loads evenly, reducing localized pressure and preventing piston collapse. Manufactured in Germany.

Features

• High-compression forged piston for increased performance
• Big bore design for enhanced displacement
• Optimized heat transfer for improved efficiency
• Elliptical design ensures uniform bearing surface under heat expansion
• Even thrust load distribution to prevent piston collapse
• Manufactured in Germany

Specifications

• Bore Size: 80mm (79.95mm)
• Compression Ratio: 11.5:1
• Part Number: 8678D700
• Lock Part Number: CW19
• Pin Part Number: WP028
• Ring Set Part Number: 800XDS
• Stroke: 59.60mm
• Clearance: 0.05mm
• OEM Compression Ratio: 10.4:1
• Dome Volume: -1.40 cm³
• Compression Height: 24.00mm

Vehicle Fitments

• Suzuki DR-Z250 (2001-2007)

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
