WOSSNER 68mm FORGED PISTON KIT YAMAHA IT200 1984-1986

Wossner Piston Kit - 8176D200 is a high-quality forged piston designed for Yamaha IT200 models from 1984 to 1986. Manufactured in Germany, this piston is engineered for optimal heat transfer and uniform bearing surface distribution, reducing localized pressure and preventing piston collapse.

Features

• Forged piston for superior strength and durability
• Engineered for optimal combustion chamber heat transfer
• Elliptical design for uniform bearing surface and reduced piston collapse
• Manufactured in Germany
• Compatible with available top-end bearing (Part No. B1005)

Specifications

• Bore Size: 68.00mm
• Actual Bore Diameter: 67.94mm
• Display (cm³): 195
• Stroke (mm): 57.00
• Clearance (mm): 0.06
• Compression Ratio: 2-Stroke
• OEM Compression Ratio: 2-Stroke
• Compression Height (mm): 30.00

Included Items

• Lock (Part No. CW16)
• Wrist Pin (Part No. WP027)
• Ring Set (Part No. RSB6800 x 2)

Cross-Reference OEM Part Numbers

• 8176D200

Vehicle Fitments

• 1984 Yamaha IT200
• 1985 Yamaha IT200
• 1986 Yamaha IT200

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
