PISTON KIT 84-86 IT200 66.50 FORGED WOSSNER 8176D050

Piston Kit 66.50mm Bore 66.40 Wossner 8176D050 (+0.50)

YAMAHA IT200 1984-1986

Wossner forged pistons are superior in strength and design. Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls. Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse. Made in Germany.

• Lock P/N: CW16
• Pin P/N: WP027
• Ring Set P/N: RSB6650 x 2

Specifications:

• Display (cm3): 195
• Hub Stroke (mm): 57.00
• Clearance (mm): 0.06
• Wossner Compression Ratio: 2 Stroke
• OEM Compression Ratio: 2 Stroke
• Dome Volume (cm3):
• Compression Height (mm): 30.00
• Theoretical Weight (G):

Compatible Models:

• 1984-1986 Yamaha IT 200

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
