PISTON KIT 02-04 610/400 91.50 WOSSNER 8550DB HUSQVARNA

Piston Kit Details:

• Piston Kit: Wossner 8550DB (+0.01)
• Bore: 91.50mm
• Wossner Part Number: 8550DB

Husqvarna Models:

• TC 400 1999 - 2001
• SMR400 2005 - 2007

Wossner Piston Features:

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Additional Part Information:

• PART NO.: 56-W104.B
• Wossner Piston Part Number: 8550DB
• Lock Part Number: CW20
• Pin Part Number: WP038
• Ring Set Part Number: 915XSY

Technical Specifications:

• Displacement (cm3): 399
• Hub Stroke (mm): 60.80
• Clearance (mm): 0.06
• Wossner Compression Ratio: OEM
• OEM Compression Ratio: 11.40:1
• Dome Volume (cm3): +1.90
• Compression Height (mm): 24.50
