HOT RODS CON ROD KIT SUZUKI RM250 86-95, RMX250 89-98

Connecting rod kit for Suzuki RM 250 (1986–1995) and Suzuki RMX 250 (1989–1998) models. This premium kit is engineered for high-performance applications and ensures durability under demanding conditions.

Features:

• Manufactured from hot-rolled ASTM 4115 material and case-hardened to 58-62 Rc for exceptional strength.
• Strategically designed with side scalloping and vent slots to minimize bearing race distortion at high RPMs.
• Double-forged rods ensure improved grain flow and dimensional consistency.
• Shot-peened and double-honed for maximum durability under heavy loads.
• Small ends are double-drilled for enhanced lubrication and cooling of the wrist pin bearing.
• Thrust washers and crank pin bearings are silver-coated for improved lubricity and wear resistance.
• Complete kit includes connecting rod, crankpin, crankpin bearing, top-end bearing, and thrust washers.

Specifications:

• Centre to Centre: 128.00 mm
• Big End Bore Ø: 32.00 mm
• Big End Width: Not specified
• Pin Diameter: 24.00 mm
• Pin Length: 57.70 mm
• Small End Bore Ø: 23.00 mm
• Small End Width: Not specified
• Washer Thickness: Not specified

Cross-Reference OEM Part Numbers:
HOTRODS 8105, SUZUKI: 12161-00B00, 12161-05D00, 12161-28C30

Vehicle Fitment:

• Suzuki RM 250 (1986–1995)
• Suzuki RMX 250 (1989–1998)

Part Number: 56-988.HR

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
