WOSSNER CON ROD KIT KAWASAKI KX250F 04-09, SUZUKI RM-Z250 04-23
WOSSNER CON ROD KIT KAWASAKI KX250F 04-09, SUZUKI RM-Z250 04-23
Couldn't load pickup availability
KAWASAKI
KXF250 KX250F 2004-2009,
SUZUKI
RM-Z250 RMZ250 2004-2018,
CONNECTING, CONROD REBUILDING KIT WOSSNER P4002 �
- Made in Germany
- Heavy-duty OE replacement connecting rods.
- Certified Chorme alloy steel provides superior strength.
- Crankpins are manufactured from hot-rolled ASTM steel and case hardened.
- Psychic Rods uses the latest in caged needle roller bearing designs for high rpm longevity.
- Thrust washers are manufactured from bronze phosphor and are silver coated.
- Rod assembly sold complete with rod, crankpin, crankpin bearing, top end bearing and thrust washers if need.
- Fully Compatible with after market and OE crankshafts.
- Material SNCM220,
| SIZE | MM |
| Centre 2 Centre | 92.50 |
| Small End Bearing | None |
| Small End Bore � | 16 |
| Small End Width | 15.00 |
| Big End Bearing | 30x38x18.8 |
| Big End Bore � | 38 |
| Big End Width | 19.00 |
| Big End Pin � | 30 |
| Big End Pin Length | 55.00 |
| Washer Thickness | 1.00 |
Part No. 56-936.WO (oro2u.com)
Cross reference numbers.
HOTROD 8622, WOSSNER P4002, WISECO WPR201, PSYCHIC MX-09050
Majority of our listings are for a direct replacement for your original part.
Our parts are made of quality and are designed to meet or exceed the original OEM Standards.
Our products are often a cost effective alternative to genuine OEM Parts.
Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
