PSYCHIC CON ROD KIT SUZUKI RM125 1988-1996

Connecting rod rebuild kit for Suzuki RM125 (1988–1996), engineered as a heavy-duty OE replacement. Built using certified chrome alloy steel for enhanced durability and longevity, this complete assembly is compatible with both aftermarket and OE crankshafts.

Features

• Heavy-duty connecting rod designed as an OE replacement.
• Constructed from certified chrome alloy steel for superior strength.
• Crankpins are hot-rolled ASTM steel and case-hardened for durability.
• Utilizes advanced caged needle roller bearing designs for high rpm performance.
• Thrust washers made from bronze phosphor with a silver coating.
• Complete assembly includes rod, crankpin, crankpin bearing, top-end bearing, and thrust washers if required.
• Fully compatible with aftermarket and OE crankshafts.

Specifications

• Material: SNCM220
• Centre-to-Centre: 105 mm
• Small End Bearing: 15x19x19.80 mm
• Small End Bore Ø: 19 mm
• Small End Width: 18 mm
• Big End Bearing: 22x28x15.8 mm
• Big End Bore Ø: 28 mm
• Big End Width: 16 mm
• Big End Pin Ø: 22 mm
• Big End Pin Length: 53 mm
• Washer Thickness: 1.0 mm

Cross Reference OEM Part Numbers

• Suzuki: 12161-01B41
• Suzuki: 12161-27C00-0B0
• Suzuki: 12161-27C00-0D0
• Suzuki: 12161-27C10
• Suzuki: 12161-43D00
• Hotrods 8110
• ProX 03-3207
• Wossner P2015

Vehicle Fitments

• Suzuki RM125: 1988–1996

Part Number: 56-924.DR

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
