CON ROD 54.2 PIN, YAMAHA DT125 76-81, DT175 76-81, RT180 90-98, RD125LC

YAMAHA
DT125 1978-1981,
DT125LC 1976,
RD125LC,
YT175, Tri Moto 1982 - 1983,
DT175 1976-1981,
DT175MX 1979-1981,
DT125-LC water cooled,
RT180A 1990-1998,

Connecting CONROD rod rebuild kit. PSYCHIC MX-09109

- Heavy-duty OE replacement connecting rods.
- Certified Chorme alloy steel provides superior strength.
- Crankpins are manufactured from hot-rolled ASTM steel and case hardened.
- Psychic Rods uses the latest in caged needle roller bearing designs for high rpm longevity.
- Thrust washers are manufactured from bronze phosphor and are silver coated.
- Rod assembly sold complete with rod, crankpin, crankpin bearing, top end bearing and thrust washers if need.
- Fully Compatible with after market and OE crankshafts.
- Material SNCM220,
SIZE

Please see the image Key. A=105, B=16, C=22, E=16, D=16, F=54.30 all size mm.

Specification:
TOP/BOTTOM BEARING
KV 16X20X19.6 W/NATURAL COATING,
KT 22X28X15.6MM COPPER COATING Material: SCM415

Part No. 56-247.DR (oro2u.com)

Cross reference numbers ONLY.
VESRAH VA-2003, MX-09109, [25V-11651-00-00 + 3M5-11681-00-00 + 93310-422C8-00 + 90209-22248-00 + 93310-216E1-00] L23-41030, MX-09109 1V0-11651-00 4Y2-11651-00

�

Application: YAMAHA 1976 DT125C, YAMAHA 1978-1981 DT125, YAMAHA 1976 DT175C,

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
