PSYCHIC CON ROD YAMAHA YFS200 BLASTER 1988-2006

YAMAHA
YFS200 Blaster 1988-2006,

CONNECTING ROD REBUILD KIT BRONCO AT-97307

- High-quality replacement kits are manufactured from hot-rolled ASTM 4115 and case-hardened.
- Rods are double-forged to improve grain flow and maintain dimensional consistency.
- Rods are also shot-peened and double-honed for superior strength under heavy loads.
- Small ends are drilled to supply extra lubrication and cooling to the wrist pin bearing, which is especially important when the piston crown is close to the wrist pin bearing
- Thrust washers and crank pin bearings are silver-coated for added lubricity.
- Kits sold complete with rod, crank pin, crank pin bearing, top end bearing, needle cage bearing, and thrust washers

Center To Center (mm): 110
Big End Bearing (mm):
Big End Bore (mm): 29
Big End Width (mm):
Big End Pin Diameter (mm): 22
Big End Pin Length (mm): 56.40
Small End Bearing (mm):
Small End Bore (mm): 21
Small End Width (mm):
Washer Thickness (mm): 1.00

Part No. 56-195.DR

Cross reference numbers.
VESRAH VA-2009, WOSSNER P203, WISECO WPR170, PSYCHCIC AT- 97307, HOTROD 8144, 43G-11651-00-00,

Assemblies where 2TV-11651-00-00 is used
1992 WR200RD - Crankshaft Piston
1984 IT200L - Crankshaft - Piston
1985 IT200N - Crankshaft - Piston
1986 IT200S - Crankshaft-Piston
1986 IT200S - Piston-Connector Rod Assembly
1988 BLASTER (YFS200U) - Crankshaft Piston
1989 BLASTER (YFS200W) - Crankshaft Piston
1990 BLASTER (YFS200A) - Crankshaft Piston
1991 BLASTER (YFS200B) - Crankshaft Piston
1991 BLASTER (YFS200B_MN) - Crankshaft Piston
1992 BLASTER (YFS200D) - Crankshaft Piston
1992 BLASTER (YFS200D_MN) - Crankshaft Piston
1993 BLASTER (YFS200E) - Crankshaft Piston
1993 BLASTER (YFS200E_MN) - Crankshaft Piston
1994 BLASTER (YFS200F) - Crankshaft Piston
1994 BLASTER (YFS200F_MN) - Crankshaft Piston
1995 BLASTER (YFS200G) - Crankshaft Piston
1995 BLASTER (YFS200G_MN) - Crankshaft Piston
1996 BLASTER (YFS200H) - Crankshaft Piston
1996 BLASTER (YFS200H_MN) - Crankshaft Piston
1997 BLASTER (YFS200J) - Crankshaft Piston
1997 BLASTER (YFS200J_MN) - Crankshaft Piston
1998 BLASTER (YFS200K) - Crankshaft Piston
1999 BLASTER (YFS200L) - Crankshaft Piston
2000 BLASTER (YFS200M) - Crankshaft Piston
2001 BLASTER (YFS200N) - Crankshaft Piston
2002 BLASTER (YFS200P) - Crankshaft Piston
2003 BLASTER (YFS200R) - Crankshaft Piston
2004 BLASTER (YFS200S) - Crankshaft Piston
2005 BLASTER (YFS200T) - Crankshaft Piston
2006 BLASTER (YFS200V) - Crankshaft Piston
2006 BLASTER SE (YFS200SEV) - Crankshaft Piston

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
