SHOCK FRONT POLARIS 7041784 BRONCO AU-04310, RANGER

Part No. 29-569

FRONT SHOCK FITMENT

• POLARIS RANGER 500 1999
• POLARIS RANGER SERIES 10
• POLARIS RANGER SERIES 11
• POLARIS RANGER 2X4, 4X4 2003 - 2005 (SERIES 10/11)
• POLARIS RANGER 6X6 2005 RANGER 500 6X6 2003-2005 (SERIES
• POLARIS RANGER 6X6 700 EFI 2006-2008
• POLARIS UTV 2X4 2003
• POLARIS UTV 2X4/4X4/6X6 2004
• POLARIS UTV 4X4 2003

SPECIFICATIONS

• POSITION TOP HOLE I.D MM: 12.5 X 36 THREADED ROD
• TOP EYELET WIDTH MM: 12.5 X 36 THREADED ROD
• BOTTOM HOLE I.D MM: NA
• BOTTOM EYELET WIDTH MM: NA
• TUBE O.D MM: 41.5
• STROKE MM: 147
• SPRING OD MM: 96
• SPRING WIRE DIAMETER MM: 10.5
• SPRING RATE LBS/INCH: -
• SPRING RATE KG/MM: -
• CENTRE TO CENTRE MM: 493
• CENTRE TO CENTRE IN: 19 2/5

Cross reference numbers ONLY. POLAIRS 7041784,



Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
