DIAPHRAGM & SPRING YAM.

Diaphragm & Spring Kit

Part Number: 27-2802
Manufacturer: K&L Supply

Features:

• Cost-Effective Solution: An inexpensive alternative to the original equipment (OE) assembly.
• Prevents Afterburn: Prevents afterburn generated by a lean fuel mixture when the throttle is closed.
• Enhanced Performance: The cut-off valve temporarily closes the slow-jet air passage, instantly creating a richer fuel mixture.
• Complete Rebuild Kit: This high-quality kit contains all necessary parts for a complete rebuild of one carburetor: diaphragm, spring, and O-ring.

Compatible Models:

Suzuki:

• GV1200 Madura (1985 - 1986)
• GV1400 Cavalcade (1986 - 1989)
• GV700GL Madura (1985)
• VS700 Intruder (1986 - 1987)
• VS750GL Intruder (1988 - 1991)

Yamaha:

• TDM850 (1992 - 1993)
• TTR225 (1999 - 2004)
• VMX1200 V-Max (1985 - 2005)
• XT225 (1993 - 2005)
• XVS650 V Star Custom (1998 - 2004)
• XVS650A V Star Classic (1998 - 2005)
• XVS650AT V Star Silverado (2003 - 2005)
• XVZ1200 Venture (1983 - 1984)
• XVZ1200D Venture Royale (1983 - 1985)
• XVZ1300 Venture Royale (1986 - 1993)
• YFM250 Bear Tracker (1999 - 2004)
• YFM350ER Moto-4 (1987 - 1995)
• YFM350F Wolverine 4x4 (1995 - 2005)
• YFM350FW Big Bear 4x4 (1987 - 1999)
• YFM350U Big Bear 2x4 (1996 - 1999)
• YFM350X Warrior (1987 - 2004)
• YFM400F Kodiak 4x4 (1993 - 1999)
• YFP350 (1988)

Cross Reference Numbers:

• 3LD1490H-00-00
• 26H-1490H-00-00
• 22V14940-00-00
• 13480-24B00
• 13481-05A10

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
