PISTON KIT VERTEX 24103B 80.0 B YAM YZ 250 15-18, OS+3:00 BIG BORE COMPR 14,4:1

VERTEX UK PISTON KIT � � � � 24103B � US PRO HC Comp. 14.4:1 �

All Vertex Pistons Feature: �
- Standard pistons and components are OEM replacements.
- Kits include piston, rings, wrist pin and circlips.
- All pistons are heat treated with a T-5 or T-6 hardening and tempering cycle.
- Replacement rings are sold individually.
- Made in Italy.
- Fitted in many oem bikes as STD.

SPECIFICATIONS:

• BORE SIZE. � 80.00mm BIG BORE +3.00mm [B � 79.96mm]

Replacement Parts.

• Rings. � 590280000002 SET
• Pin. � 711195
• Clips. 72055

Cross reference numbers ONLY.

• Piston Assy 1SM-116A0-10-00
• Piston (Std) 1SM-11631-10-00
• Piston Ring Set (Std) 1SM-11603-00-00
• Pin, Piston 1SM-11633-20-00
• Circlip 93450-17129-00

MODEL FITMENT

• YAMAHA YZ 250F 2015-2018 US-PRO BIG BORE COMPR 14,4:1

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
