STARTER MOTOR HONDA CB500X 13-19, ARROWHEAD 410-54263, 31200-MGZ-J81

Starter Motor - Arrowhead 410-54263

Compatibility:
Honda Model:

• Honda CB500X (2013-2018, 471cc)

Specifications:

• Type: Permanent Magnet Direct Drive (PMDD)
• Shaft OD: 11.9 mm
• B+ Stud: 6 mm x 1.0

Mounting Holes:

• Right Hand: 6.2 mm OD
• Left Hand: 7.0 mm OD
• Field Case Length: 61.1 mm
• Field Case Width: 61 mm OD
• Shaft Length: 21.6 mm + 3.9 mm Shoulder
• Length from DE Bearing to End of Shaft: 25 mm
• Overall Length (Approx.): 161 mm

Features:

• Meets or exceeds OEM quality.
• Direct OEM replacement with stock mounting locations.
• Designed to handle increased power loads.
• Best value for money.
• Made to OEM specifications, matching original equipment appearance.
• All electrical parts are 100% factory tested before shipping.
• Easy installation; consult a professional if unsure.
• Note: No Returns on Electrical Parts.

Cross Reference Numbers:

• 410-54263

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
