CABLE CLUTCH 97-17 YZ80 YZ85, PSYCHIC 105-224 4ES-26335-11

YAMAHA

• YZ85 (2002-2017)
• YZ80 (82cc) (1997-2001)
• YZ80 (79cc) (1997-2001)

Part: CABLE CLUTCH PSYCHIC 105-224
Features:

• Clutch cable assembly
• Black PVC outer jacket for maximum flexibility and durability
• Steel inner casing is tightly coiled for low compression ratios
• Pre-lubricated nylon inner sleeve guarantees smooth operation and long life
• All wire ends are bird-caged to terminal casting for superior pull-out resistance
• EPDM molded rubber components for high UV resistance and long life

Approximate Size:

• Housing Length: 830mm
• Ferrule end Top OD: 7.40mm
• Ferrule end Bot OD: 9.80mm (Top hat type)
• Travel: 100 to 115mm when using mid way adjuster
• Cable Top Mid Adjuster: provides 16mm of adjustment with rubber cover
• Nipple Top end Barrel: 8x10mm with rubber boot for lever
• Nipple Bot end Barrel: 8x10mm with rubber wire cover
• Inner Wire: 2.0mm


Cross Reference Numbers Only:

• 4ES-26335-11-00
• 1SN-26335-00-00
• MOTION PRO 05-0224
• VENHILL Y01-3-033
• 14-150.MP
• 14-150.PX
• 14-150.VH
• 14-150_AB
• ALLBALLS 45-2037
• PROX 53.120037

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
