GR5 SWING ARM PIN KIT KX500 88-04, KDX200/220, KLX300 33032-1137 & 92015-1407

Factory Image Racing> Giving your machine the Factory look!

KAWASAKI �SWINGARM KIT

50% lighter then standard & strong then steel.

• Material: Aerospace Grade 5 (6Al/4V)
• Thread D: M14
• Pitch P: 1.50mm
• OD spindle : 14.95mm

• Overall length L: 225mm
• Thread length : 18mm

• Head: � 19mm SPANNER

• KIT : SPINDLE & NUT

• WEIGHT: 151.3g spindle only!


The steel OEM spindle weights 269.3g and the titanium spindle weights 151.3g. big weight saver!!

No more rusty hardware, Titanium is Corrosion proof. CNC machined from super-strong grade 5. titanium alloy used for its high strength super light properties, also fantastic anti- corrosion properties. Used in every application from Motorcycles � & much more.

Cross references numbers only: 33032-1137 & 92015-1407

FITMENT:

Kawasaki Motorcycle 1994 KLX250R - KLX250-D2 Rear suspension
Kawasaki Motorcycle 1993 KDX200 - KDX200-E5 Swing Arm
Kawasaki Motorcycle 1991 KX125 - KX125-H2 Swing Arm
Kawasaki Motorcycle 1989 KDX200 - KDX200-E1 Swing Arm
Kawasaki Motorcycle 1992 KDX200 - KDX200-E4 Swing Arm
Kawasaki Motorcycle 1991 KDX200 - KDX200-E3 Swing Arm
Kawasaki Motorcycle 1991 KX250 - KX250-H2 Swing Arm
Kawasaki Motorcycle 1990 KX250 - KX250-H1 Swing Arm
Kawasaki Motorcycle 1990 KDX200 - KDX200-E2 Swing Arm
Kawasaki Motorcycle 1990 KX125 - KX125-H1 Swing Arm
Kawasaki Motorcycle 1994 KDX200 - KDX200-E6 Swing Arm
Kawasaki Motorcycle 1989 KX500 - KX500-E1 Swing Arm(KX500-E1)
Kawasaki Motorcycle 1991 KX500 - KX500-E3 Swing Arm(KX500-E2/E3)
Kawasaki Motorcycle 1990 KX500 - KX500-E2 Swing Arm(KX500-E2/E3)
Kawasaki Motorcycle 1988 KX250 - KX250-F1 Swingarm
Kawasaki Motorcycle 2001 KX500 - KX500-E13 Swingarm
Kawasaki Motorcycle 1998 KLX300R - KLX300-A3 Swingarm
Kawasaki Motorcycle 1998 KX500 - KX500-E10 Swingarm
Kawasaki Motorcycle 1997 KX500 - KX500-E9 Swingarm
Kawasaki Motorcycle 1999 KDX200 - KDX200-H5 Swingarm
Kawasaki Motorcycle 1999 KDX220R - KDX220-A6 Swingarm
Kawasaki Motorcycle 2002 KX500 - KX500-E14 Swingarm
Kawasaki Motorcycle 2003 KDX220R - KDX220-A10 Swingarm
Kawasaki Motorcycle 2004 KLX300R - KLX300-A9 Swingarm
Kawasaki Motorcycle 1997 KLX300R - KLX300-A2 Swingarm
Kawasaki Motorcycle 1992 KX500 - KX500-E4 Swingarm
Kawasaki Motorcycle 1999 KLX300R - KLX300-A4 Swingarm
Kawasaki Motorcycle 1993 KX500 - KX500-E5 Swingarm
Kawasaki Motorcycle 2001 KLX300R - KLX300-A6 Swingarm
Kawasaki Motorcycle 1996 KDX200 - KDX200-H2 Swingarm
Kawasaki Motorcycle 1995 KLX250R - KLX250-D3 Swingarm
Kawasaki Motorcycle 1995 KX500 - KX500-E7 Swingarm
Kawasaki Motorcycle 1994 KDX250 - KDX250-D4 Swingarm
Kawasaki Motorcycle 2004 KDX220R - KDX220-A11 Swingarm
Kawasaki Motorcycle 2004 KX500 - KX500-E16 Swingarm
Kawasaki Motorcycle 2004 KDX200 - KDX200-H10 Swingarm
Kawasaki Motorcycle 1988 KX500 - KX500-D1 Swingarm
Kawasaki Motorcycle 1989 KX125 - KX125-G1 Swingarm
Kawasaki Motorcycle 1992 KDX250 - KDX250-D2 Swingarm
Kawasaki Motorcycle 1995 KDX200 - KDX200-H1 Swingarm
Kawasaki Motorcycle 1994 KX500 - KX500-E6 Swingarm
Kawasaki Motorcycle 1994 KLX250R - KLX250-D2 Swingarm
Kawasaki Motorcycle 1996 KX500 - KX500-E8 Swingarm
Kawasaki Motorcycle 1996 KLX250R - KLX250-D4 Swingarm
Kawasaki Motorcycle 1991 KDX250 - KDX250-D1 Swingarm
Kawasaki Motorcycle 1989 KX250 - KX250-G1 Swingarm
Kawasaki Motorcycle 1988 KX125 - KX125-F1 Swingarm
Kawasaki Motorcycle 1997 KDX200 - KDX200-H3 Swingarm
Kawasaki Motorcycle 2003 KLX300R - KLX300-A8 Swingarm
Kawasaki Motorcycle 1993 KDX250 - KDX250-D3 Swingarm
Kawasaki Motorcycle 1998 KDX200 - KDX200-H4 Swingarm
Kawasaki Motorcycle 2000 KDX220R - KDX220-A7 Swingarm
Kawasaki Motorcycle 2000 KDX200 - KDX200-H6 Swingarm
Kawasaki Motorcycle 2002 KDX200 - KDX200-H8 Swingarm
Kawasaki Motorcycle 2002 KDX220R - KDX220-A9 Swingarm
Kawasaki Motorcycle 2002 KLX300R - KLX300-A7 Swingarm
Kawasaki Motorcycle 2001 KDX200 - KDX200-H7 Swingarm
Kawasaki Motorcycle 2001 KDX220R - KDX220-A8 Swingarm
Kawasaki Motorcycle 1997 KDX220R - KDX220-A4 Swingarm
Kawasaki Motorcycle 1999 KX500 - KX500-E11 Swingarm
Kawasaki Motorcycle 1998 KDX220R - KDX220-A5 Swingarm
Kawasaki Motorcycle 2003 KX500 - KX500-E15 Swingarm
Kawasaki Motorcycle 2003 KDX200 - KDX200-H9 Swingarm
Kawasaki Motorcycle 2000 KLX300R - KLX300-A5 Swingarm
Kawasaki Motorcycle 2000 KX500 - KX500-E12 Swingarm

�

Majority of our listings are for a direct replacement for your original part.

Our parts are made of quality and are designed to meet or exceed the original OEM Standards.

Our products are often a cost effective alternative to genuine OEM Parts.

Please note: the models of bike we state in our listings are for general guidance only. Please make sure this item will fit your bike before purchasing. Also, we cannot guarantee fitment to any non-UK models.
